Aluminum Shell Wire Wound Resistor

Aluminum shell wire wound resistor is a tubular resistor, containing a ceramic resistor component and a CuNi or CrNi made resistor winding. Usually it is mounted on the angle bracket or PCB board if necessary. Besides, we can also provide silicone coating surface and additive label following requirements.

• Rated power: 800W, the maximum resistant instantaneous impact power is 1000W;
• Under room temperature, insulation resistance between the terminal and casing is ≥10MΩ；
• Dielectric strength between the terminal and casing is 2600V.
